| Dimensions | 180 × 120 × 70 mm (H x W x D) |
|---|---|
| Weight | Approx. 1 kg |
| Supply Voltage | 24 V DC, 1 A |
| Protection Class | IP20 |
| Calculated Loss | Approx. 3 W |
| Fibre-Optic Channels | 2 information channels (channel 2 on DAPM 100 only) |
| Mounting | In the driver's console |
| Included | Cabin indication / operator alert unit approx. 80 × 120 mm with 1 m cable |
Quote on request
Lead time: 1–3 weeks (made to order) — exact lead time confirmed at quotation.
Quote on request
Lead time: 1–3 weeks (made to order) — exact lead time confirmed at quotation.
Quote on request
Lead time: 1–3 weeks (made to order) — exact lead time confirmed at quotation.
Quote on request
Lead time: 1–3 weeks (made to order) — exact lead time confirmed at quotation.
Get a fast quote — send the part number, and we'll reply with a quote in 24–36 hours.
Ask on WhatsAppThe operator interface module of the ABB ASTAT crane motion controller, mounted in the driver's cabin console and linked to the control module by fibre optics.
Legacy product line, discontinued by the manufacturer. Supplied as a sourced spare on request. ABB's stated modern equivalent is the ACS880 drive with the Crane Control program (option +N5050).
The DAPM cabin input/output module is the link between the crane driver and the ABB ASTAT control system.
It sits in the driver's console, reads the master switch and other cabin controls, and drives an operator alert indication panel of roughly 80 by 120 mm supplied with a 1 m cable. It talks to the DARA control system module over fibre optics, so there is no long copper signal run from the cabin to the panel.
DAPM 100 handles both analog and digital signals and is the model to pick if load cell functions are needed. DAPM 101 is digital only and suits a stepped master switch with no second operator station. The +HD heavy-duty versions use a metal case and are rated to +70 degrees Celsius instead of +55.
3ASC25H221 (Type: DAPM 100)
| I/O | 8 digital inputs at 24 V DC, 8 digital outputs for the LED alert panel, 2 analog inputs, 2 analog outputs |
|---|---|
| Enclosure | Plastic |
| Max Ambient Temperature | +55 °C |
| No-Load Loss | 3 W |
| Full-Load Loss | 4 W (inputs high) |
Must be selected if load cell functions are required.
Need a replacement? Send us the part number from the unit's label.
